Battery Maximizer Kit - Occasional User

Battery Maximizer Kit - Occasional User


Description:

Maximize your battery's charge for peak performance and extended battery life with the occasional user (1-2 Days/Week Use) battery maximizer kit. Our kit includes a 1.5 Amp A/C Panel Mount Charger and 2-Watt Solar Charger/Maintainer to keep your trailer circuit batteries charged for occasional use. Each battery maximizer kit is assembled to fit your demand from your equipment!

Download: Battery Maximizer Kit Brochure & Battery Circuit Setup



Benefits:

  • Increase battery efficiency
  • Reduce sulfate build-up
  • Extend battery life up to 3-5X longer



Specifications:

This 1.5 Amp panel mount charger allows for a simple overnight charge for full next-day use when plugged into an available A/C outlet.

  • Input: AC 120V, 60HzA
  • Output: DC 12V, 1.5 amp
  • Charge Current: Max. 1.5 Amp
  • Type of Battery Used: 12V Lead-Acid Battery
  • Efficiency: >90%
  • Battery Cables: 24 In., 16 AWG
  • Lead Wire: 3-Prong Plug
  • Size: 175mmX015mmX60mm
  • Weight: 1.0 kg



The 2-Watt SolarPulse Charger/Maintainer combines ReNew-IT Pulse Technology® with an exceptional charging system. ReNew-It Technology safely prevents the main cause of battery problems and failure including sulfate buildup on lead-acid battery plates. Used extensively by U.S. Military and consumers worldwide for over ten years, this technology has been scientifically proven by two major universities to make batteries work harder and last longer than you ever thought possible.

  • Pulse Frequency: 22-28 KHz
  • Max Charging DC Voltage: 16.5V, 250 mA
  • Reverse Polarity Protected: Yes
  • Circuit Box Dimensions: 3.25" X 2.25" X 1.5"
  • Solar Panel Dimensions: 4.75" X 8.56" X .125"
  • Box to Lugs Wire Length: 3 feet
  • Box to Panel Wire Length: 17 feet
  • Termination: .375" Lugs
